Massey Ferguson 7718S


Massey Ferguson 7718S tractor photo
2018 - 2021
7700S Series
Row-Crop tractor
Series map:
7716S
7718S
150.0hp
165.0hp
Production
ManufacturerMassey Ferguson (a part of AGCO)
Row-Crop tractor
FactoriesJackson, Minnesota, USA
 Beauvais, France
Massey Ferguson 7718S Engine
AGCO Power 6.6L 6-cyl diesel
Fuel tank82 gal
310.4 L
Exhaust fluid (DEF)8 gal
30.3 L
Engine details ...
Massey Ferguson 7718S Transmissions
24-speed six-speed power shift
continuously-variable transmission
48-speed creeper
Transmission details ...
Massey Ferguson 7718S Power
Engine165 hp
123.0 kW
PTO (claimed)135 hp
100.7 kW
Drawbar (tested)126.6 hp
94.4 kW
PTO (tested)165.6 hp
123.5 kW
Performance test details ...
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with air-conditioning. Available cab suspension. Massey Ferguson auto-guidance ready
Hydraulics
Typeclosed-center load-sensing
Pressure2900 psi
200.0 bar
Rear valves2 or 3
Front valves0 to 3
Pump flow29 gpm
109.8 lpm
 50 gpmOptOptional
189.3 lpm
Tractor hitch
Rear TypeIII/II
Controlelectronic draft control
Dyna-6 Rear lift (at ends)12345 lbs
5599 kg
Dyna-VT Rear lift (at ends)16314 lbs
7400 kg
Front lift (at ends)6172 lbs
2799 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000
Engine RPM540@1980
 540E@1530
 1000@2030
 1000E@1570
Dimensions & Tires
Wheelbase113.2 inches
287 cm
Weight13889 to 14638 pounds
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
7718S references literature
7700S Series published in 2020, by Massey Ferguson*
*Publication contains known errors.
