J.I. Case CF 400


J.I. Case CF 400 tractor photo
1967 - ????
Utility tractor
Production
Manufacturer:J.I. Case
Type:Utility tractor
Factory:Vierzon, France
J.I. Case CF 400 Power
Engine:40 hp
29.8 kW
Mechanical
Chassis:4x2 2WD
Final drives:planetary
Differential lock:mechanical rear
Steering:manual
Brakes:mechanical drum
Cab:Open operator station.
Transmission:8-speed gear
Transmission details ...
Photos
No photos of the J.I. Case CF 400 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:13.2 gal
50.0 L
Hydraulic system:1.9 gal
7.2 L
Hydraulics
Capacity:1.9 gal
7.2 L
Tractor hitch
Rear Type:II/I
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Mid PTO:independent
Mid RPM:1000
Dimensions & Tires
Wheelbase:72.8 inches
184 cm
Weight:3946 lbs
1789 kg
Front tire:6.00-16
Rear tire:12-28
Full dimensions and tires ...
