Fendt 938 Vario MT


Fendt 938 Vario MT tractor photo
2020 -
900 Vario Series
Agricultural Crawler tractor
Series map:
938 Vario MT
940 Vario MT
374.0hp
399.6hp
Production
ManufacturerFendt (a part of AGCO)
Agricultural Crawler tractor
Built in Jackson, Minnesota, USA
Fendt 938 Vario MT Engine
AGCO Power 9.8L 7-cyl diesel
Engine details ...
Fendt 938 Vario MT Power
Engine (gross)374 hp
278.9 kW
Mechanical
Drivecrawler
Cab standard with air-conditioning.
Photos
No photos of the Fendt 938 Vario MT are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel180 gal
681.3 L
 215 galOptOptional
813.8 L
 257 galOptOptional
972.7 L
Exhaust fluid (DEF)18.8 gal
71.2 L
Hydraulic system33 gal
124.9 L
Hydraulics
Typeclosed center
Capacity33 gal
124.9 L
Pressure2900 psi
200.0 bar
Valves4 to 6
Pump flow58 gpm
219.5 lpm
 116 gpm*Optional combined flow of dual pumps.
439.1 lpm
SCV flow37 gpm
140.0 lpm
 45 gpm*Optional, with 0.625 or 0.75 inch couplers.
170.3 lpm
Tractor hitch
Rear TypeIVN/III
Controlposition and draft control
Rear lift (at ends)19000 lbs
8618 kg
Rear lift (at 24"/610mm)16500 lbs
7484 kg
DrawbarCat. 4
Power Take-off (PTO)
Rear PTOindependent
Rear RPM1000/1000E (1.75)
Engine RPM1000@1650
1000E@1225
Dimensions & Tracks
Wheelbase101 inches
256 cm
Weight33443 to 33667 pounds
14-inch tracks
Full dimensions and tracks ...
Electrical
Groundnegative
Charging systemalternator
Charging amps300 *Dual 150A alternators.
Batteries2
Battery volts12
Battery AH185
References
938 Vario MT references literature
900 Vario MT Series published in 2020, by Fendt
900 Vario MT Series published in 2020, by Fendt
