Fendt 1159 MT
|
|
| Production | |
| Manufacturer | Fendt (a part of AGCO) |
| Agricultural Crawler tractor | |
| Variants | |
| MT865E | similar Challenger model |
| Fendt 1159 MT Engine | |
| AGCO Power 16.8L 12-cyl diesel | |
| Fuel tank | 264.2 gal 1000.0 L |
| Exhaust fluid (DEF) | 28 gal 106.0 L |
 Engine details ... | |
| Fendt 1159 MT Transmission | |
| 16-speed full power shift | |
 Transmission details ... |
| Fendt 1159 MT Power | |
| Engine (gross) | 540.4 hp 403.0 kW |
| Engine (max) | 583.3 hp 435.0 kW |
| Mechanical | |
| Drive | crawler |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Fendt 1159 MT are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | closed center pressure flow compensated |
| Pressure | 2901 psi 200.0 bar |
| Rear valves | 6 OptOptional |
| Pump flow | 59.2 gpm 224.1 lpm |
| 84.8 gpmOptOptional 321.0 lpm | |
| SCV flow | 37 gpm 140.0 lpm |
| Tractor hitch | |
| Rear Type | IV/III |
| Rear lift | 30865 lbs 14000 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 |
| Engine RPM | 1000@1980 |
| Dimensions & Tracks | |
| Wheelbase | 118.1 inches 299 cm |
| Weight | 42692 lbs 19365 kg |
| 27.5-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Fednt 1100 MT published in 2019, by Fendt |
