Challenger MT856
| 2021 - |
MT800 Series | Agricultural Crawler tractor |
|
Production |
Manufacturer: | Challenger (a part of AGCO)
|
Type: | Agricultural Crawler tractor
|
Challenger MT856 Power |
Engine (gross): | 556.5 hp 415.0 kW
|
Mechanical |
Chassis: | crawler
|
Cab: | Cab standard with air-conditioning.
|
Transmission: | continuously-variable transmission
|
Transmission details ... |
Photos |
No photos of the Challenger MT856 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics |
Type: | closed center pressure-flow compensated
|
Pressure: | 2900 psi 200.0 bar
|
Rear valves: | 4 to 8
|
Pump flow: | 58.1 gpm 219.9 lpm
|
| 116.2 gpm 439.8 lpm *Optional
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Rear RPM: | 1000/1000E
|
Electrical |
Ground: | negative
|
Charging system: | alternator
|
Charging amps: | 325
|
Batteries: | 3
|
Battery volts: | 12
|
