Fendt Farmer 307Ci
| 2003 - 2008 |
Farmer 300 Series |
|
Production |
Manufacturer: | Fendt (a part of AGCO)
|
Fendt Farmer 307Ci Power |
Engine (net): | 73.8 hp 55.0 kW
|
Mechanical |
Chassis: | 4x2 2WD
|
| 4x4 MFWD 4WD
|
Steering: | power
|
Brakes: | hydraulic disc
|
Cab: | Cab standard with heat. Air-conditioning optional.
|
Transmissions: | 21-speed synchronized
|
| 21-speed shuttle
|
Transmission details ... |
Photos |
No photos of the Fendt Farmer 307Ci are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics |
Type: | open center
|
Pressure: | 2900 psi 200.0 bar
|
Valves: | 2 to 4
|
Pump flow: | 18.5 gpm 70.0 lpm
|
Tractor hitch |
Rear Type: | III/II
|
Rear lift: | 10979 lbs 4980 kg
|
Front lift: | 6493 lbs 2945 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Rear RPM: | 540/750/1000
|
Front PTO: | independent*Optional
|
Front RPM: | 540
|
| 1000
|
Electrical |
Ground: | negative
|
Charging system: | alternator
|
Charging amps: | 95
|
Charging volts: | 14
|
Battery volts: | 12
|
Battery AH: | 90
|
