Massey Ferguson GC1723E
| | 2019 - 2024 |
| GC1700 Series | | Sub-Compact Utility tractor |
|
Series map:
GC1723E
GC1725M
22.5hp
24.5hp
| Production |
| Manufacturer | Massey Ferguson (a part of AGCO)
|
| Sub-Compact Utility tractor |
| Original price was $11,156 in 2020 |
| Variants |
| GC1723E | tractor
|
| GC1723EB | backhoe-loader tractor
|
| Massey Ferguson GC1723E Power |
| Engine (gross) | 22.5 hp
16.8 kW
|
| Engine (net) | 21.6 hp
16.1 kW
|
| PTO (claimed) | 18.7 hp
13.9 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | mechanical rear
|
| Power steering |
| Wet disc brakes |
| Two-post fixed ROPS. Folding ROPS on GC1723EB backhoe package. |
| Hydraulics |
| Type | open center
|
| Pressure | 1920 psi
132.4 bar
|
| Pump flow | 4.3 gpm
16.3 lpm
|
| Total flow | 6.3 gpm
23.8 lpm
|
| Steering flow | 2.0 gpm
7.6 lpm
|
| Steering press. | 1209 psi
83.4 bar
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 1191 lbs
540 kg
|
| Rear lift (at 24"/610mm) | 661 lbs
299 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | mechanical wet disc
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2532
|
| Mid PTO | independent
|
| Mid PTO Type | 2000 (1.00)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 40
|
| Battery CCA | 433
|
| Battery volts | 12
|
| References |
 |
| MF GC1700 Series published in 2023, by Massey Ferguson |
| GC1700E/M Series published in 2019, by Massey Ferguson |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on October 4, 2025 |
