Deutz-Fahr 4046E Keyline


Deutz-Fahr 4046E Keyline tractor photo
2018 -
4E Keyline Series
Utility tractor
Series:4046E Keyline4050E Keyline
Production
Manufacturer:Deutz-Fahr
Type:Utility tractor
Deutz-Fahr 4046E Keyline Power
Engine:44.3 hp
33.0 kW
Deutz-Fahr 4046E Keyline Engine
Simpson 2.7L 3-cyl diesel
Fuel tank:14.5 gal
54.9 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Differential lock:mechanical
Steering:power
Cab:Open operator station. Two-post ROPS available.
Transmissions:8-speed gear
 12-speed creeper
 8-speed partially synchronized
Transmission details ...
Photos
No photos of the Deutz-Fahr 4046E Keyline are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Valves:2 to 4
Pump flow:7.1 gpm
26.9 lpm
Tractor hitch
Rear Type:II
Rear lift:2756 lbs
1250 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
 540/540E*Optional
 540/1000*Optional
Dimensions & Tires
2WD Wheelbase:75.6 inches
192 cm
4WD Wheelbase:76.8 inches
195 cm
Weight:4630 to 5512 pounds
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
