Yanmar EF328
|
|
| Production | |
| Manufacturer | Yanmar |
| Compact Utility tractor | |
| Yanmar EF328 Engine | |
| Yanmar 1.5L 3-cyl diesel | |
| Fuel tank | 9.5 gal 36.0 L |
 Engine details ... | |
| Yanmar EF328 Transmission | |
| 16-speed four-speed power shift | |
 Transmission details ... |
| Yanmar EF328 Power | |
| Engine | 27.6 hp 20.6 kW |
| Mechanical | |
| Four-wheel drive |
| Photos | |
| No photos of the Yanmar EF328 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| Rear lift | 3307 lbs 1500 kg |
| Power Take-off (PTO) | |
| Rear PTO | 540 (1.375) |
| Engine RPM | 547@2600 |
| 755@2600 | |
| 955@2600 | |
| 1248@2600 | |
| -600@2600 | |
| Dimensions & Tires | |
| Wheelbase | 64.6 inches 164 cm |
| Weight | 2976 to 3395 pounds |
| Front tire | 7-16 |
| Rear tire | 12.4-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| EF300 Series (41812-011884) published in 2004 |
