Fendt Farmer 260V
|
|
| Production | |
| Manufacturer | Fendt |
| Orchard/Vineyard tractor | |
| Fendt Farmer 260V Engine | |
| KHD 3.1L 3-cyl diesel | |
| Fuel tank | 15.85 gal 60.0 L |
 Engine details ... | |
| Fendt Farmer 260V Power | |
| Engine | 59 hp 44.0 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Mechanical drum brakes | |
| Two-post mid-mount folding ROPS. Cab available with heat and air-conditioning. |
| Photos | |
 | |
 Fendt Farmer 260V photos... | |
| Hydraulics | |
| Pressure | 2611 psi 180.0 bar |
| Total flow | 12.9 gpm 48.8 lpm |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/750 |
| 540/750/1000 OptOptional | |
| Dimensions & Tires | |
| 2WD Wheelbase | 77.8 inches 197 cm |
| 4WD Wheelbase | 77.5 inches 196 cm |
| Weight | 4233 to 4652 pounds |
| Front tire | 6.00-16 |
| 2WD Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 55 |
| Charging volts | 14 |
| Battery volts | 12 |
| Battery AH | 88 |
| References | |
 | |
| Farmer 250V 260V 270V 280V 280P published in 1996, by Fendt | |
| Innovations for 1988 published by Fendt |
