Tractors > John Deere > 60C

John Deere 60C

John Deere 60C tractor photo
2005 - 2015   Milenio C Series
Compact Utility tractor
Series next:John Deere 70C
Series back:John Deere 50C






Production:

Distributor:John Deere
Manufacturer:Goldini
Factory:Italy


John Deere 60C Engine:

   VM Motori 2.1L 3-cyl diesel
full engine details ...


Capacity:

Fuel:13.2 gal [50.0 L]


3-Point Hitch:

Rear Type:II/I
Rear lift (at ends):5071 lbs [2300 kg]
Rear lift (at 24"/610mm):3197 lbs [1450 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/540E
Engine RPM:540@2430
540E@1874


Dimensions & Tires:

Wheelbase:66.5 inches [168 cm]
Weight:4189 lbs [1900 kg]
Front tire:240/70R16
Rear tire:320/70R24
full dimensions and tires ...


60C Serial Numbers:


how to read serial numbers...



John Deere 60C Power:

Engine (gross):58 hp [43.3 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:power
Brakes:mechanical wet disc
Cab:Two-post mid-mount folding ROPS. Cab optional.


Hydraulics:

Pressure:2611 psi [180.0 bar]
Pump flow:10.3 gpm [39.0 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:55


Battery:

Volts:12
