Kubota M4072
| | 2018 - 2020 |
| M4002 Series | | Utility tractor |
|
| Production |
| Manufacturer: | Kubota
|
| Type: | Utility tractor
|
| Kubota M4072 Power |
| Engine (gross): | 74 hp
55.2 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Two-post folding ROPS. Cab optional.
|
| Transmissions: | 18-speed
|
| | 36-speed
|
 Transmission details ... |
| Photos |
| No photos of the Kubota M4072 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Valves: | 2 or 3
|
| Pump flow: | 16.6 gpm
62.8 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | position and draft control
|
| Rear lift (at ends): | 5512 lbs
2500 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/540E
|
| | 540/1000*Optional
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Battery volts: | 12
|
| Page information |
| Last update: | March 5, 2021
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
