Huber 40-62

Huber 40-62 tractor photo
1927 - 1941
Standard-tread tractor
25-50 Super Four
Series:32-45 Super Four40-62
Type:Standard-tread tractor
Factory:Marion, Ohio, USA
Huber 40-62 Power
Drawbar (claimed):40 hp
29.8 kW
Belt (claimed):62 hp
46.2 kW
Drawbar (tested):50.03 hp
37.3 kW
Belt (tested):69.76 hp
52.0 kW
power test details ...
Huber 40-62 Engine
Stearns 10.1L 4-cyl gasoline
Fuel tank:55 gal
208.2 L
Engine details ...
Chassis:4x2 2WD
Cab:Open operator station.
Transmission:2-speed gear
Transmission details ...
Dimensions & Tires
Wheelbase:95 inches
241 cm
Weight:9760 lbs
4427 kg
Front tire:40x7
Rear tire:56x20
Full dimensions and tires ...
Belt Pulley
Diameter:15.5 inches
39 cm
Width:9.375 inches
23 cm
