Tractors > Kubota > B2231

Kubota B2231

Kubota B2231 tractor photo
2018 -    B2 Series
Compact Utility tractor
Previous model:Kubota B2350
Series next:Kubota B2261
Series back:Kubota B2201






Production:

Manufacturer:Kubota


Kubota B2231 Engine:

   Kubota 1.1L 3-cyl diesel
full engine details ...


Capacity:

Fuel:7.1 gal [26.9 L]


3-Point Hitch:

Rear Type:I
Control:position control
Rear lift (at ends):2138 lbs [969 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540 (1.375)
Mid PTO:optional
Mid RPM:2500 (Kubota 10-tooth #5)


Dimensions & Tires:

ROPS Wheelbase:59.1 inches [150 cm]
Cab Wheelbase:61.4 inches [155 cm]
Weight:1874 to 2381 pounds
full dimensions and tires ...


Kubota B2231 attachments:

 mowing deck
 front-end loader
all B2231 attachments ...


B2231 Serial Numbers:


how to read serial numbers...



Kubota B2231 Power:

Engine (gross):22.7 hp [16.9 kW]
Engine (net):20.4 hp [15.2 kW]
PTO (claimed):16.8 hp [12.5 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Differential lock:mechanical rear
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional with air-conditioning.


Hydraulics:

Pressure:2347 psi [161.8 bar]
Total flow:8.7 gpm [32.9 lpm]


Electrical:

Ground:negative
Charging system:alternator


Battery:

Number:1
Volts:12


Page information:

Last update:November 5, 2018
Copyright:Copyright 2018 TractorData LLC
Contact:Peter@TractorData.com
©2000-2018 - TractorData™. Notice: Every attempt is made to ensure the data listed is accurate. However, differences between sources, incomplete listings, errors, and data entry mistakes do occur. Consult official literature from the manufacturer before attempting any service or repair.
