Kubota JB11


No photo available
2006 - 2008
JB Bullstar Series
Sub-Compact Utility tractor
Series:JB11JB13
JB11X
Production
Manufacturer:Kubota
Type:Sub-Compact Utility tractor
Kubota JB11 Power
Engine:10.3 hp
7.7 kW
Kubota JB11 Engine
Kubota 0.5L 2-cyl diesel
Fuel tank:3.7 gal
14.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:manual
Brakes:wet disc
Cab:Two-post ROPS.
Transmission:6-speed
Transmission details ...
Photos
No photos of the Kubota JB11 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear PTO:540 (1.375)
Rear RPM:523:3000
 917:3000
Dimensions & Tires
Wheelbase:50 inches
127 cm
Weight:1102 lbs
499 kg
Front tire:4.00-10
Rear tire:7-14
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
