Tractors > Kubota > GL277

Kubota GL277

Kubota GL277 tractor photo
1996 - 2001   GL Series
Compact Utility tractor
Previous model:Kubota GL268
Series next:Kubota GL281
Series back:Kubota GL261






Production:

Manufacturer:Kubota


Kubota GL277 Engine:

   Kubota 1.5L 3-cyl diesel
full engine details ...


Capacity:

Fuel:7.1 gal [26.9 L]


3-Point Hitch:

Rear Type:I
Rear lift:2083 lbs [944 kg]


Power Take-off (PTO):

Rear RPM:6568/803/985/1304 (1.375)


Dimensions & Tires:

Wheelbase:64.8 inches [164 cm]
Weight:2601 to 3020 pounds
Front tire:7-16
Rear tire:11.2-24
full dimensions and tires ...


GL277 Serial Numbers:


how to read serial numbers...



Kubota GL277 Power:

Engine:26.7 hp [19.9 kW]
PTO (claimed):26.2 hp [19.5 kW]


Mechanical:

Chassis:4x4 MFWD 4WD
Steering:power
Brakes:mechanical wet disc
Cab:Two-post ROPS. Cab optional.


Hydraulics:

Pump flow:6.1 gpm [23.1 lpm]


Electrical:

Ground:negative


Battery:

Number:1
Volts:12
