Kubota GL261
|
|
| Production | |
| Manufacturer | Kubota |
| Compact Utility tractor | |
| Kubota GL261 Engine | |
| Kubota 1.5L 3-cyl diesel | |
| Fuel tank | 7.1 gal 26.9 L |
 Engine details ... | |
| Kubota GL261 Transmissions | |
| 16-speed gear | |
| 16-speed power shift | |
 Transmission details ... |
| Kubota GL261 Power | |
| Engine | 26.7 hp 19.9 kW |
| PTO (claimed) | 26.2 hp 19.5 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Mechanical wet disc brakes | |
| Two-post ROPS. Cab optional. |
| Photos | |
| No photos of the Kubota GL261 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 6.1 gpm 23.1 lpm |
| Tractor hitch | |
| Rear Type | JIS1 |
| Rear lift | 2083 lbs 944 kg |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 568@2600 |
| 803@2600 | |
| 985@2600 | |
| 1304@2600 | |
| -803@2600 | |
| Dimensions & Tires | |
| Wheelbase | 64.8 inches 164 cm |
| Weight | 2601 to 3020 pounds |
| Front tire | 7-16 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| GL (T0270-1920-8) published in 1996 |
