RK Tractors RK55S


RK Tractors RK55S tractor photo
2017 -
Compact Utility tractor
TYM built
Series:RK37SRK55S
Production
Distributor:RK Tractors (a part of Rural King)
Manufacturer:TYM
Type:Compact Utility tractor
Original price:$21,799 (2017 )
Variants
RK55S:shuttle ROPS
RK55H:hydrostatic ROPS
RK55SC:shuttle cab
RK55HC:hydrostatic cab
RK Tractors RK55S Power
Engine (gross):55.1 hp
41.1 kW
PTO (claimed):44.9 hp
33.5 kW
RK Tractors RK55S Engine
Yanmar 2.1L 4-cyl diesel
Fuel tank:17 gal
64.3 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post ROPS.
Transmission:16-speed mechanical shuttle
Transmission details ...
Photos
No photos of the RK Tractors RK55S are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Valves:2
Pump flow:9.5 gpm
36.0 lpm
Total flow:14.5 gpm
54.9 lpm
Steering flow:5 gpm
18.9 lpm
Tractor hitch
Rear Type:I
Control:position and draft control
Rear lift (at ends):3314 lbs
1503 kg
Rear lift (at 24"/610mm):2945 lbs
1335 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540 (1.375)
Dimensions & Tires
Wheelbase:76.2 inches
193 cm
Weight:3814 lbs
1730 kg
Front tire:9.5x16
Rear tire:14.9x24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:70
Battery volts:12
