| | Production: |
| Manufacturer: | Zetor
|
| Factory: | Brno, Czech Republic
|
| | |
| Zetor 4.2L 4-cyl diesel |
| full engine details ... | | | Capacity: |
| | |
| Rear Type: | II
|
| Control: | position control and mechanical top-link draft sensing
|
| Rear lift: | 9442 lbs [4282 kg]
|
| | |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| | 540/540E
|
| Front RPM: | 1000
|
| | |
| 2WD Wheelbase: | 91.4 inches [232 cm]
|
| 4WD Wheelbase: | 88 inches [223 cm]
|
| Weight: | 6900 to 8003 pounds
|
| Front tire: | 7.5-16
|
| 2WD Rear tire: | 16.9-28
|
| full dimensions and tires ... | | | Proxima 70 Serial Numbers: |
- Serial numbers unknown -
|
|
|
|
| | Zetor Proxima 70 Power: |
| Engine (net): | 65 hp [48.5 kW]
|
| | Mechanical: |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | hydraulic wet disc
|
| Trailer brakes: | hydraulic*Optional
|
| | pneumatic*Optional
|
| Cab: | Cab standard with optional air-conditioning.
|
| | Hydraulics: |
| Pressure: | 2611 psi [180.0 bar]
|
| Valves: | 1
|
| Total flow: | 13.2 gpm [50.0 lpm]
|
| | Electrical: |
| Charging system: | alternator
|
