New Holland T8.410
|
|
| Production | |
| Manufacturer: | New Holland |
| Type: | Row-Crop tractor |
| Factory: | Racine, Wisconsin, USA |
| Original price: | $334,083 (2016 powershift ) |
| Variants | |
| T8.410: | wheeled tractor |
| T8.410 SmartTrax: | half-track |
| New Holland T8.410 Power | |
| Engine (gross): | 340 hp 253.5 kW |
| Engine (max): | 409 hp 305.0 kW |
| PTO (claimed): | 290 hp 216.3 kW |
| PTO (tested): | 336.17 hp 250.7 kW |
| New Holland T8.410 Engine | |
| FPT 8.7L 6-cyl diesel | |
| CVT Fuel tank: | 163 gal 617.0 L |
| FPS Fuel tank: | 179 gal 677.5 L |
| Exhaust fluid (DEF): | 26 gal 98.4 L |
 Engine details ... | |
| Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Final drives: | inboard planetary |
| Steering: | power |
| Brakes: | wet disc |
| Cab: | Cab standard with air-conditioning. Comfort Ride cab suspension optional. Intellisteer ready |
| Transmissions: | 18-speed full power shift |
| continuously variable transmission (CVT) | |
| 23-speed power shift creeper | |
 Transmission details ... | |
| Photos | |
 | |
 New Holland T8.410 photos... | |
| Hydraulics | |
| Type: | closed center pressure-flow compensating (PFC) |
| Valves: | 4 to 5 |
| Pump flow: | 44 gpm 166.5 lpm |
| 75 gpm 283.9 lpm *Optional, MegaFlow rate. | |
| Tractor hitch | |
| Rear Type: | III/IIIN |
| IVN/III | |
| Control: | electronic lower-link draft sensing |
| Rear lift: | 15900 lbs 7212 kg *Lift capacity with Cat. 3 hitch and 43-inch link arms. |
| 17900 lbs 8119 kg (Lift capacity with Cat. 3 hitch and 38-inch link arms.)) | |
| 17500 lbs 7938 kg *Lift capacity with Cat. 4 hitch and 43-inch link arms. | |
| 19500 lbs 8845 kg (Lift capacity with Cat. 4 hitch and 38-inch link arms.)) | |
| Drawbar: | Cat. 4 |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 1000 |
| 540/1000*Optional | |
| Front PTO: | independent*Optional |
| Front RPM: | 1000 (1.375) |
| Dimensions & Tires | |
| FPS Wheelbase: | 136 inches 345 cm |
| CVT Wheelbase: | 138 inches 350 cm |
| Weight: | 22663 lbs 10279 kg |
| Front tire: | 420/85R34 |
| Rear tire: | 480/80R50 |
 Full dimensions and tires ... | |
| New Holland T8.410 attachments | |
| front-end loader | |
 Attachment details ... |
| T8.410 Serial Numbers | |
| 2015: | ZERxxxxxx |
| 2016: | ZFRxxxxxx |
| 2017: | ZGRxxxxxx |
| 2018: | ZHRxxxxxx |
| 2019: | ZJRxxxxxx |
| 2020: | ZKRxxxxxx |
| 2021: | ZLRxxxxxx |
| Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 200 |
| Batteries: | 2 |
| Battery volts: | 12 |
