Antonio Carraro TTR 3800

Antonio Carraro TTR 3800 tractor photo






Production:

Manufacturer:Antonio Carraro


Antonio Carraro TTR 3800 Engine:

   Lombardini 1.6L 3-cyl diesel
full engine details ...


Capacity:

Fuel:7.9 gal [29.9 L]


3-Point Hitch:

Rear Type:I
Rear lift:4078.6 lbs [1850 kg]
Front Hitch:I*Optional
Front lift:882 lbs [400 kg]


Power Take-off (PTO):

Rear RPM:540/1000 (1.375)


Dimensions & Tires:

Wheelbase:51.2 inches [130 cm]
Weight:2150 lbs [975 kg]
Front tire:6.50x16
Rear tire:6.50x16
full dimensions and tires ...


TTR 3800 Serial Numbers:


- Serial numbers unknown -



Antonio Carraro TTR 3800 Power:

Engine:36 hp [26.8 kW]


Mechanical:

Chassis:4x4 articulated 4WD
Steering:articulated power
Brakes:mechanical drum
Cab:Two-post fixed ROPS.


Electrical:

Ground:negative


Battery:

Volts:12
