Tractors > Challenger > MT545E

Challenger MT545E

No photo available
2015 -    MT500E Series
Row-Crop tractor
Previous model:Challenger MT545D
Series next:Challenger MT555E
Series back:Challenger MT535E



Factory:Jackson, Minnesota, USA

Challenger MT545E Engine:

   AGCO Power 6.6L 6-cyl diesel
full engine details ...


Fuel:80 gal [302.8 L]
Exhaust fluid (DEF):8 gal [30.3 L]
Hydraulic system:15.9 gal [60.2 L] (AP6)
 26.4 gal [99.9 L] (CVT)

3-Point Hitch:

Rear Type:II
Rear lift (at ends):8900 lbs [4037 kg]
 15500 lbs [7030 kg] *Lift capacity with CVT transmission.
Front Hitch:II
Front lift (at ends):6200 lbs [2812 kg]

Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000

Dimensions & Tires:

full dimensions and tires ...

MT545E Serial Numbers:

- Serial numbers unknown -

Challenger MT545E Power:

Engine (gross):165 hp [123.0 kW]
Engine (max):200 hp [149.1 kW]
PTO (claimed):135 hp [100.7 kW]


Chassis:4x4 MFWD 4WD
Differential lock:electro-hydraulic front and rear
Brakes:hydraulic wet disc
Cab:Cab standard with air-conditioning. Auto-Guide 3000


Type:closed-center load sensing
Capacity:15.9 gal [60.2 L] (AP6)
 26.4 gal [99.9 L] (CVT)
Pressure:2900 psi [200.0 bar]
Valves:3 or 4
SCV flow:26.4 gpm [99.9 lpm]
Total flow:29 gpm [109.8 lpm]
 50 gpm [189.3 lpm] *Optional with CVT


Charging system:alternator
