Challenger MT535E Tests
|
|
| Tractor Tests | |
| OECD 2992: diesel AutoPower VI 4WD | |
| OECD 2989: diesel TechStar CVT 4WD |
| OCED Tractor Test 2992 | |||
| |||
| OCED Tractor Test 2992 | |
| Diesel AutoPower VI 4WD May 2016 - August 2016, Link: OCED Tractor Test 2992 file | |
| PTO performance | |
| Max power | 150.2 hp 112.0 kW |
| Fuel use | 8.1 gal/hour 30.7 l/hour |
| Power at rated engine speed | 141.1 hp 105.2 kW |
| Fuel use | 8.1 gal/hour 30.7 l/hour |
| Power at rated PTO speed | 149.4 hp 111.4 kW |
| Fuel use | 8.4 gal/hour 31.8 l/hour |
| Drawbar performance | |
| Max power | 125.1 hp 93.3 kW |
| Fuel use | 8.1 gal/hour 30.7 l/hour |
| Gear 3B used for power test. | |
| Max pull | 13625 lbs 6180 kg |
| Gear 1F used for pull test. | |
| OCED Tractor Test 2989 | |||
| |||
| OCED Tractor Test 2989 | |
| Diesel TechStar CVT 4WD July 2016 - August 2016, Link: OCED Tractor Test 2989 file | |
| PTO performance | |
| Max power | 154.9 hp 115.5 kW |
| Fuel use | 8.8 gal/hour 33.3 l/hour |
| Power at rated engine speed | 147.5 hp 110.0 kW |
| Fuel use | 8.6 gal/hour 32.6 l/hour |
| Power at rated PTO speed | 152.2 hp 113.5 kW |
| Fuel use | 8.5 gal/hour 32.2 l/hour |
| Drawbar performance | |
| Max power | 121.9 hp 90.9 kW |
| Fuel use | 8.9 gal/hour 33.7 l/hour |
| Pull at 10.1KPH | |
| Max pull | 15465 lbs 7014 kg |
| Pull at 4.14KPH | |
