Kubota BX2680
| | 2017 - |
| BX80 Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | Kubota
|
| Type: | Compact Utility tractor
|
| Original price: | $13,347 (2017 )
|
| Kubota BX2680 Power |
| Engine: | 24.8 hp
18.5 kW
|
| PTO (claimed): | 19.5 hp
14.5 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Two-post foldable ROPS.
|
| Transmission: | hydrostatic
|
 Transmission details ... |
| Hydraulics |
| Pump flow: | 6.2 gpm
23.5 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at 24"/610mm): | 680 lbs
308 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540 (1.375)
|
| Mid RPM: | 2500
|
| BX2680 Serial Numbers |
| Location: | Serial number decal on the right side of the tractor frame, above the front axle.
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Battery volts: | 12
|
| Page information |
| Last update: | July 25, 2021
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
