Yanmar YT235


Yanmar YT235 tractor photo
2016 -
YT2 Series
Compact Utility tractor
Production
Manufacturer:Yanmar
Type:Compact Utility tractor
Variants
YT235:ROPS
YT235C:cab
Yanmar YT235 Power
Engine (gross):34.2 hp
25.5 kW
Engine (net):32 hp
23.9 kW
PTO (claimed):27 hp
20.1 kW
Yanmar YT235 Engine
Yanmar 1.6L 3-cyl diesel
Fuel tank:7.4 gal
28.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post ROPS. Cab optional with air-conditioning.
Transmission:hydrostatic
Transmission details ...
Hydraulics
Pump flow:7.1 gpm
26.9 lpm
Steering flow:4.1 gpm
15.5 lpm
Tractor hitch
Rear Type:I
Rear lift (at ends):2205 lbs
1000 kg
Rear lift (at 24"/610mm):1764 lbs
800 kg
Power Take-off (PTO)
Rear RPM:540
Mid RPM:2013
Dimensions & Tires
Wheelbase:65 inches
165 cm
Weight:2558 to 2910 pounds
Front tire:6-14
Rear tire:9.5-22
Full dimensions and tires ...
Yanmar YT235 attachments
60" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
Electrical
Ground:negative
Charging system:alternator
ROPS Charging amps:40
Cab Charging amps:55
Battery CCA:540
Battery volts:12
