CaseIH Farmall 45C CVT


CaseIH Farmall 45C CVT tractor photo
2015 - 2018
Farmall C Series
Compact Utility tractor
Series:Farmall 40CFarmall 45C CVTFarmall 50C
Production
Manufacturer:CaseIH
Type:Compact Utility tractor
Original price:$35,558 (2016 ROPS )
Original price:$44,450 (2016 Cab )
CaseIH Farmall 45C Power
Engine:46 hp
34.3 kW
PTO (claimed):36 hp
26.8 kW
CaseIH Farmall 45C Engine
FPT 2.2L 3-cyl diesel
Fuel tank:13 gal
49.2 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post folding ROPS. Cab optional.
Transmission:Continuously Variable Transmission (CVT)
Transmission details ...
Photos
No photos of the CaseIH Farmall 45C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Rear valves:1 or 2*Optional
Mid valves:2
Pump flow:9.8 gpm
37.1 lpm
Tractor hitch
Rear Type:I
Control:position control
Rear lift (at ends):3541 lbs
1606 kg
Rear lift (at 24"/610mm):2800 lbs
1270 kg
Rear Arms:telescopic link ends
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Mid RPM:2000
Dimensions & Tires
Wheelbase:73.5 inches
186 cm
Weight:4190 to 4940 pounds
Front tire:8x16
Rear tire:14.9-24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
ROPS Charging amps:75
Cab Charging amps:90
Battery volts:12
