Tractors > John Deere > 5041C

John Deere 5041C

John Deere 5041C tractor photo
2011 - 2014   5C Series
Series next:John Deere 5042C
Series back:John Deere 5039C






Production:

Manufacturer:John Deere
Factory:Pune, Maharashtra, India


John Deere 5041C Engine:

   John Deere 2.9L 3-cyl diesel
full engine details ...


Capacity:

Fuel:11.9 gal [45.0 L]


3-Point Hitch:

Rear Type:II
Control:position and draft control
Rear lift (at ends):2205 lbs [1000 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540 (1.375)
Engine RPM:540@1575


Dimensions & Tires:

Wheelbase:73.6 inches [186 cm]
Weight:3814 lbs [1730 kg]
Front tire:6.0x16
Rear tire:12.4x28
full dimensions and tires ...


5041C Serial Numbers:


- Serial numbers unknown -



John Deere 5041C Power:

Engine:41 hp [30.6 kW]


Mechanical:

Chassis:4x2 2WD
Steering:manual
Steering:power*Optional
Brakes:wet disc
Cab:Open operator station.


Hydraulics:

Type:open center
Pump flow:5.3 gpm [20.1 lpm]
Steering flow:4.7 gpm [17.8 lpm]


Electrical:

Ground:negative
Charging system:alternator
Charging amps:40


Battery:

Number:1
Volts:12
Amp-hours:88
