Tractors > McCormick Intl > C75 Max

McCormick Intl C75 Max

No photo available
2004 - 2007   C-Max Series
Utility tractor
Series next:McCormick Intl C85 Max
Series back:McCormick Intl C60 Max






Production:

Manufacturer:Argo
Factory:Doncaster, England


McCormick Intl C75 Max Engine:

   Perkins 4.4L 4-cyl diesel
full engine details ...


Capacity:

Fuel:27 gal [102.2 L]


3-Point Hitch:

Rear Type:II
Control:position and draft control
Rear lift (at ends):5732 lbs [2600 kg]
 8157 lbs [3700 kg] *Optional


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/750
 540/1000


Dimensions & Tires:

2WD Wheelbase:92.2 inches [234 cm]
4WD Wheelbase:91.2 inches [231 cm]
Weight:7165 to 7253 pounds
Front tire:12.4-24
Rear tire:16.9-30
full dimensions and tires ...


C75 Max Serial Numbers:


- Serial numbers unknown -



McCormick Intl C75 Max Power:

Engine:68.2 hp [50.9 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post ROPS. Cab optional.


Hydraulics:

Type:open center
Pressure:2611 psi [180.0 bar]
Valves:2 to 4
Pump flow:13.8 gpm [52.2 lpm]
Total flow:21.7 gpm [82.1 lpm]
Steering flow:7.9 gpm [29.9 lpm]


Electrical:

Ground:negative
Charging system:alternator


Battery:

Volts:12
