Shibaura SD4340
| | 1977 - 1980 |
| SD Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | Shibaura
|
| Type: | Compact Utility tractor
|
| Shibaura SD4340 Power |
| Engine: | 43 hp
32.1 kW
|
| PTO (claimed): | 36 hp
26.8 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | mechanical rear
|
| Steering: | power
|
| Brakes: | mechanical drum
|
| Cab: | Open operator station. Available two-post ROPS and canopy.
|
| Transmission: | 24-speed gear
|
 Transmission details ... |
| Photos |
| No photos of the Shibaura SD4340 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel: | 9.2 gal
34.8 L
|
| Hydraulic system: | 9.2 gal
34.8 L
|
| Hydraulics |
| Type: | open center
|
| Capacity: | 9.2 gal
34.8 L
|
| Pressure: | 2133 psi
147.1 bar
|
| Valves: | 1 or 2
|
| Pump flow: | 7.1 gpm
26.9 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Control: | position and draft control
|
| Rear lift (at ends): | 4343 lbs
1969 kg
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| Rear RPM: | 540 (1.375)
|
| Engine RPM: | 546@2500
701@2500
1042@2500
1320@2500
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 20
|
| Battery volts: | 12
|
| Battery AH: | 100
|
