John Deere 5515 Hi-Crop
|
|
| Production | |
| Distributor | John Deere |
| Manufacturer | Carraro |
| Utility tractor | |
| Variants | |
| 5515 | utility tractor |
| 5515F | narrow tractor |
| 5515V | narrow low-profile tractor |
| 5515HC | High Crop high clearance tractor |
| John Deere 5515 Hi-Crop Engine | |
| John Deere 4.5L 4-cyl diesel | |
 Engine details ... |
| John Deere 5515 Hi-Crop Transmissions | |
| 12-speed partially synchronized | |
| 24-speed partially synchronized | |
| 24-speed two-speed power shift | |
 Transmission details ... |
| John Deere 5515 Hi-Crop Power | |
| Engine (gross) | 82 hp 61.1 kW |
| Engine (net) | 80 hp 59.7 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Steering | hydrostatic power |
| Hydraulic wet disc brakes | |
| Trailer brakes | hyraulic *Optional. |
| Four-post ROPS. Cab optional. | |
| Photos | |
| No photos of the John Deere 5515 Hi-Crop are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 21.1 gal 79.9 L |
| Rear axle | 3.2 qts*Rear drop axles, each side. 3.0 L |
| Hydraulics | |
| Type | open center |
| Pressure | 1900 psi 131.0 bar |
| Pump flow | 12.4 gpm 46.9 lpm |
| 15.8 gpm (optional) 59.8 lpm | |
| Steering flow | 6.5 gpm 24.6 lpm |
| Steering press. | 2700 psi 186.2 bar |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift | 5395 lbs 2447 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | dry disc |
| Rear PTO Type | 540/540E |
| 540/1000 | |
| Engine RPM | 540@1938 |
| 540E@1648 | |
| 1000@1962 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 78.7 inches 199 cm |
| 4WD Wheelbase | 85.8 inches 217 cm |
| Weight | 7231 to 7496 pounds |
| Front tire | 7.50-20 |
| Rear tire | 13.6R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| ROPS Charging amps | 40 |
| Cab Charging amps | 65 |
| Battery volts | 12 |
| References | |
 | |
| 5515 Series High Crop Tractors published in 2004, by John Deere |
