Kubota L1-26


Kubota L1-26 tractor photo
1983 - 1985
L1 Series
Compact Utility tractor
Series:L1-24L1-26L1-28
Production
Manufacturer:Kubota
Type:Compact Utility tractor
Variants
L1-26DT:4WD
Kubota L1-26 Power
Engine:25.6 hp
19.1 kW
Kubota L1-26 Engine
Kubota 1.5L 4-cyl diesel
Fuel tank:7.7 gal
29.1 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Brakes:wet disc
Cab:Open operator station.
Transmission:16-speed shuttle
Transmission details ...
Photos
No photos of the Kubota L1-26 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:I
Power Take-off (PTO)
Rear RPM:540/770/940/1250 (1.375)
Dimensions & Tires
Wheelbase:66.3 inches
168 cm
Weight:2381 to 2535 pounds
Front tire:5.00-15
2WD Rear tire:12.4-24
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
