UTB/Universal S445


UTB/Universal S445 tractor photo
1972 - 1981
Agricultural Crawler tractor
Production
Manufacturer:UTB/Universal
Type:Agricultural Crawler tractor
Factory:Brasov, Romania
Variants
SV445:narrow
S445:standard
SM445:wide-track
U445:wheeled tractor
UTB/Universal S445 Power
PTO (claimed):42 hp
31.3 kW
UTB/Universal S445 Engine
UTB 2.3L 3-cyl diesel
Fuel tank:14.3 gal
54.1 L
Engine details ...
Mechanical
Chassis:crawler
Brakes:band
Cab:Open operator station.
Transmission:6-speed constant mesh
Transmission details ...
Photos
No photos of the UTB/Universal S445 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pressure:2475 psi
170.7 bar
Pump flow:5.8 gpm
22.0 lpm
Tractor hitch
Rear Type:II/I
Rear lift:2650 lbs
1202 kg
Power Take-off (PTO)
Rear RPM:540
Engine RPM:540@1970
Dimensions & Tracks
Wheelbase:51.9 inches
131 cm
Weight:5600 lbs
2540 kg
250mm track (SV445)
Full dimensions and tracks ...
Electrical
Charging system:alternator
Battery volts:12
