Massey-Harris 16 Pacer
| | 1953 - 1955 |
| Row-Crop tractor |
|
| Production |
| Manufacturer: | Massey-Harris
|
| Type: | Row-Crop tractor
|
| Massey-Harris 16 Pacer Power |
| Plows: | 2*12-inch
|
| Drawbar (tested): | 17.05 hp
12.7 kW
|
| Belt (tested): | 18.87 hp
14.1 kW
|
| power test details ... |
| Mechanical |
| Chassis: | 4x2 2WD
|
| Final drives: | spur gear
|
| Steering: | manual
|
| Brakes: | mechanical contracting band
|
| Cab: | Open operator station.
|
| Transmission: | 3-speed gear
|
 Transmission details ... |
| Photos |
| No photos of the Massey-Harris 16 Pacer are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| | live*Optional
|
| Rear RPM: | 540
|
| Engine RPM: | 540@1800
|
| 16 Pacer Serial Numbers |
| Location: | Serial number plate on right side of tractor frame.
|
| 1954: | 50001
|
| 1955: | 51613
|
| 1956: | 52771
|
how to read serial numbers...
|
| Belt Pulley |
| Diameter: | 5.5 inches
13 cm
|
| Width: | 5.5 inches
13 cm
|
| RPM: | 1990
|
| Speed: | 3125 ft/min
952.50 meters/min
|
