Kubota L3301


Kubota L3301 tractor photo
2014 - 2022
L01 Standard Series
Compact Utility tractor
Series map:
L2501
L3301
L3901
24.8hp
33.0hp
37.5hp
Production
ManufacturerKubota
Compact Utility tractor
Kubota L3301 Engine
Kubota 1.8L 3-cyl diesel
Fuel tank11.1 gal
42.0 L
Engine details ...
Kubota L3301 Transmissions
8-speed synchronized shuttle
hydrostatic
Transmission details ...
Kubota L3301 Power
Engine (gross)33 hp
24.6 kW
Engine (net)31.4 hp
23.4 kW
Gear PTO (claimed)27.7 hp
20.7 kW
Hydro PTO (claimed)26.2 hp
19.5 kW
Mechanical
Drive4x2 2WD *Gear only
 4x4 MFWD 4WD
Steeringpower
Mechanical wet disc brakes
Two-post folding ROPS.
Hydraulics
Typeopen center
Pressure2347 psi
161.8 bar
Pump flow6.3 gpm
23.8 lpm
Steering flow3.8 gpm
14.4 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)1985 lbs
900 kg
Rear lift (at 24"/610mm)1433 lbs
650 kg
Power Take-off (PTO)
Rear PTOtransmission *Gear
 live *Hydro
Clutchoverrunning dry disc
Rear PTO Type540 (1.375)
Dimensions & Tires
Wheelbase63.3 inches
160 cm
Weight2557 to 2778 pounds
Front tire5.00-15
2WD Rear tire11.2-24
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Charging volts12
Battery CCA580
Battery volts12
References
L3301 references literature
L L3301/L3901/L4701 published in 2012, by Kubota
