Tractors > John Deere > 6195R

John Deere 6195R



John Deere 6195R tractor photo
2015 - 2021
6R Series
Row-Crop tractor
Series map:
6175R
6195R
6215R
175.0hp
195.0hp
215.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
Original price was $173,991 in 2017
John Deere 6195R Engine
John Deere 6.8L 6-cyl diesel
Fuel tank88.5 gal
335.0 L
Exhaust fluid (DEF)5.3 gal
20.1 L
Engine details ...
John Deere 6195R Transmissions
16-speed partial power shift
20-speed partial power shift
24-speed eight-speed power shift
infinitely variable transmission
Transmission details ...
John Deere 6195R Power
Engine (gross)195 hp
145.4 kW
Engine (max)235 hp
175.2 kW
PTO (claimed)159 hp
118.6 kW
Drawbar (tested)156.92 hp
117.0 kW
PTO (tested)189.23 hp
141.1 kW
Performance test details ...
Mechanical
Four-wheel drive
Final drivesinboard planetary
Power steering
Cab standard with air-conditioning.
Photos
No photos of the John Deere 6195R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center pressure flow compensated (PFC)
Pressure2900 psi
200.0 bar
Rear valves3 to 6
Pump flow41 gpm
155.2 lpm
SCV flow26.4 gpm
99.9 lpm
Tractor hitch
Rear TypeIII/IIIN
Rear lift (at 24"/610mm)9480 lbs
4300 kg
 10690 lbsOptOptional
4848 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/1000 (1.375)
 540/1000 (1.75)
 540/540E/1000 (1.375)
 540/540E/1000 (1.75)
 540E/1000/1000E (1.375)
 540E/1000/1000E (1.75)
Dimensions & Tires
Wheelbase110.2 inches
279 cm
Weight19610 lbs
8895 kg
Front tire420/90R30
Rear tire480/80R46
Full dimensions and tires ...
John Deere 6195R attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps200
 240 OptOptional
Charging volts14
Battery volts12
References
6195R references literature
Operator's Manual 6145R, 6155R, 6155RH, 6175R, 6195R and 6125R (OMAL218252) published in 2016
Operator's Manual 6145R, 6155R, 6155RH, 6175R, 6195R and 6125R (OMAL225966) published in 2021
