Tractors > John Deere > 6100B

John Deere 6100B - engine

John Deere 6100B tractor photo
2010 -
Utility tractor
Series next:John Deere 6110B
more John Deere 6100B specifications...






Engine Detail:

 John Deere 4045T
 turbocharged diesel
 4-cylinder
 liquid-cooled inline
 274.6 ci [4.5 L]
Bore/Stroke:4.173x5.00 inches [106 x 127 mm]
Power:106 hp [79.0 kW]
Fuel system:direct injection
Air cleaner:dual dry element
Compression:17:1
Rated RPM:21000
Firing order:1-3-4-2
Starter:electric
Starter volts:12
Starter power:5.6 hp [4.2 kW]
Oil capacity:13.2 qts [12.5 L]
Oil change:250 h
Coolant capacity:14.3 qts [13.5 L]
