Massey Ferguson 1726E
| | 2013 - |
| 1700 Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | Massey Ferguson (a part of AGCO)
|
| Type: | Compact Utility tractor
|
| Massey Ferguson 1726E Power |
| Engine: | 24 hp
17.9 kW
|
| Gear PTO (claimed): | 20.4 hp
15.2 kW
|
| Hydro PTO (claimed): | 19.2 hp
14.3 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Final drives: | bull gear
|
| Differential lock: | rear standard
|
| Steering: | hydrostatic power
|
| Brakes: | wet disc
|
| Cab: | Two-post foldable ROPS.
|
| Transmissions: | 9-speed gear
|
| | hydrostatic
|
 Transmission details ... |
| Photos |
| No photos of the Massey Ferguson 1726E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center gear pump
|
| SCV flow: | 6.7 gpm
25.4 lpm
|
| Total flow: | 10.5 gpm
39.7 lpm
|
| Steering flow: | 3.8 gpm
14.4 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 2205 lbs
1000 kg
|
| Rear lift (at 24"/610mm): | 1598 lbs
724 kg
|
| Power Take-off (PTO) |
| Rear PTO: | transmission
|
| Rear RPM: | 540 (1.375)
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
| Page information |
| Last update: | January 25, 2019
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
