LS U5030


LS U5030 tractor photo
2009 - ????
U Series
Utility tractor
Series:U5020U5030
Production
Manufacturer:LS
Type:Utility tractor
LS U5030 Power
Engine (gross):55 hp
41.0 kW
PTO (claimed):48 hp
35.8 kW
LS U5030 Engine
Mitsibishi 3.3L 4-cyl diesel
Fuel tank:15.9 gal
60.2 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:wet disc
Cab:Two-post foldable ROPS. Cab optional with air-conditioning.
Transmission:16-speed synchro shuttle
Transmission details ...
Photos
No photos of the LS U5030 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow:9.9 gpm
37.5 lpm
Total flow:14.7 gpm
55.6 lpm
Steering flow:4.8 gpm
18.2 lpm
Tractor hitch
Rear Type:II
Control:position and draft control
Rear lift:4079 lbs
1850 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
Dimensions & Tires
Wheelbase:80.6 inches
204 cm
Weight:4600 to 5000 pounds
Front tire:9.5-20
Rear tire:16.9-24
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:50
Battery volts:12
