Kubota L2202


Kubota L2202 tractor photo
1978 - 1985
L02 Series
Compact Utility tractor
Series map:
L2002
L2202
L2402
14.7kw
16.2kw
17.7kw
Production
ManufacturerKubota
Compact Utility tractor
Built in Japan
Variants
L22022WD
L2202DT4WD
Kubota L2202 Engine
Kubota 1.4L 3-cyl diesel
Engine details ...
Kubota L2202 Power
Engine21.7 hp
16.2 kW
Mechanical
Two- or four-wheel drive
Open operator station.
Hydraulics
Pump flow3.8 gpm
14.4 lpm
Tractor hitch
Rear TypeJIS1
Power Take-off (PTO)
Rear RPM540 (1.375)
Engine RPM556@2500
774@2500
938@2500
1250@2500
Dimensions & Tires
Wheelbase61.8 inches
156 cm
Weight1830 to 2028 pounds
Front tire4.00-15
2WD Rear tire9.5-24
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
L2202 references literature
Sunshine Tractor published by Kubota
