Allis Chalmers T16

Allis Chalmers T16 tractor photo
1963 - 1964
Four-wheel Drive (4WD) tractor
ManufacturerAllis Chalmers
Four-wheel Drive (4WD) tractor
Built in Deerfield, Illinois, USA
Total built15
The Allis-Chalmers T16 was based on the TL16 industrial loader. In field work, the tractor suffered from problems with the engine and transmission. Yellow versions of the tractor were sold through the Allis industrial division as the "Sugar Babe" for use in cane fields as a haulage tractor.
Allis Chalmers T16 Engines
Allis Chalmers 5.6L 4-cyl diesel
Allis Chalmers 7.0L 6-cyl diesel
Fuel tank75 gal
283.9 L
Engine details ...
Allis Chalmers T16 Transmission
4-speed power shift with torque converter
Transmission details ...
Allis Chalmers T16 Power
Engine135 hp
100.7 kW
Drive4x4 4WD
Final drivesplanetary
Power steering
Hydraulic brakes
Open operator station.
No photos of the Allis Chalmers T16 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Wheelbase96 inches
243 cm
Weight16300 lbs
7393 kg
Front tire20.5-25
Rear tire20.5-25
Full dimensions and tires ...
Charging systemgenerator
Battery volts12
T16 references literature
T-16 Four-Wheel-Drive-Tractor published in 1962, by Allis Chalmers
