Massey Ferguson 398
| | 1987 - 1991 |
|
| 300 Series | | Utility tractor |
|
Series map:
390
398
399
76.0hp
89.0hp
96.0hp
| Production |
| Manufacturer | Massey Ferguson
|
| Utility tractor |
| Built in Coventry, England |
| Original price | $27,400 (1988 2WD )
|
| $32,800 (1988 4WD )
|
| Massey Ferguson 398 Power |
| Engine | 89 hp
66.4 kW
|
| PTO (claimed) | 82 hp
61.1 kW
|
| Drawbar (tested) | 66.8 hp
49.8 kW
|
| PTO (tested) | 80.3 hp
59.9 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Wet disc brakes |
| Two-post ROPS. Canopy optional. |
| Photos |
| No photos of the Massey Ferguson 398 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pressure | 3000 psi
206.8 bar
|
| Pump flow | 7.2 gpm (linkage pump)
27.3 lpm
|
| | 9.5 gpm (aux. pump)
36.0 lpm
|
| Total flow | 16.8 gpm
63.6 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Control | position and draft control
|
| Rear lift | 4340 lbs*Capacity through full lift range
1968 kg
|
| Rear lift (at ends) | 5507 lbs (telescopic ends)*Capacity with links horizontal
2497 kg
|
| | 6744 lbs (fixed ends)*Capacity with links horizontal
3059 kg
|
| | 8109 lbs (fixed ends with two assist rams)*Capacity with links horizontal
3678 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000 (1.375)
|
| 398 Serial Number Location |
 |
| Serial number plate on the right side of the tractor, near the brake pedals. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 45
|
| Battery CCA | 420 (2x)
|
| | 540 (1x)
|
| Battery volts | 12
|
| References |
 |
| 300 published in 1986, by Massey Ferguson |
| 300 published in 1986, by Massey Ferguson |
| 300 Series Tractors Data Book published in 1992, by Massey Ferguson |
| M-F 300 Series Tractor Workshop Manual (1449 244M1) published in 1991 |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on June 17, 2022 |
©2000-2024 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Transmission details ...
Full dimensions and tires ...
