Massey Ferguson 375
|
|
| Production | |
| Manufacturer: | Massey Ferguson |
| Type: | Utility tractor |
| Factory: | Coventry, England |
| Original price: | $21,500 (1988 2WD ) |
| Original price: | $27,500 (1988 4WD ) |
| Massey Ferguson 375 Power | |
| Engine: | 67 hp 50.0 kW |
| PTO (claimed): | 60 hp 44.7 kW |
| Drawbar (tested): | 48.3 hp 36.0 kW |
| PTO (tested): | 58.1 hp 43.3 kW |
| Massey Ferguson 375 Engine | |
| Perkins 3.9L 4-cyl diesel | |
| Fuel tank: | 28.5 gal 107.9 L |
 Engine details ... | |
| Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | power |
| Brakes: | wet disc |
| Cab: | Two-post ROPS. Canopy optional. |
| Transmissions: | 12-speed synchromesh |
| 12-speed two-speed power shift | |
 Transmission details ... | |
| Hydraulics | |
| Type: | open center |
| Pressure: | 3000 psi 206.8 bar |
| Pump flow: | 4.4 gpm 16.7 lpm (linkage pump) 7.2 (opt. linkage pump) |
| 9.5 gpm 36.0 lpm (aux. pump) | |
| Total flow: | 13.9 gpm 52.6 lpm |
| 16.8 gpm 63.6 lpm *Optional | |
| Tractor hitch | |
| Rear Type: | II |
| Control: | position and draft control |
| Rear lift: | 4250 lbs 1927 kg *Capacity through full lift range |
| Rear lift (at ends): | 4729 lbs 2145 kg (II/I interchangeable) *Capacity with links horizontal |
| 5575 lbs 2528 kg (II/I interchangeable with assist ram) *Capacity with links horizontal | |
| 5701 lbs 2585 kg (II fixed) *Capacity with links horizontal | |
| 6744 lbs 3059 kg (II fixed with assist ram) *Capacity with links horizontal | |
| 5410 lbs 2453 kg (II wrist-action) *Capacity with links horizontal | |
| Power Take-off (PTO) | |
| Rear PTO: | live |
| Rear RPM: | 540 (1.375) |
| 540/1000 (1.375) | |
| Dimensions & Tires | |
| 2WD Wheelbase: | 84.1 inches 213 cm |
| 4WD Wheelbase: | 92.5 inches 234 cm |
| Weight: | 6040 to 7202 pounds |
| Front tire: | 7.50-16 |
| 2WD Rear tire: | 18.4/15-30 |
 Full dimensions and tires ... | |
| 375 Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor, near the brake pedals. |
| 1986: | U01001 |
| 1987: | V01001 |
| 1988: | N01001 |
| 1989: | P01001 |
| 1990: | R01001 |
| 1991: | S01001 |
| 1992: | A01001 |
| 1993: | B01001 |
| 1994: | C01001 |
| 1995: | D01001 |
| 1996: | E01001 |
| 1997: | F01001 |
| Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 45 |
| Battery CCA: | 420 (2x) |
| 540 (1x) | |
| Battery volts: | 12 |
