Wagner WA-17
| | 1961 - 1969 |
| WA Series | | Four-wheel Drive (4WD) tractor |
|
| Production |
| Manufacturer: | Wagner
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Portland, Oregon, USA
|
| Wagner WA-17 Power |
| Engine: | 250 hp
186.4 kW
|
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Final drives: | planetary
|
| Steering: | hydraulic power
|
| Brakes: | pneumatic
|
| Cab: | Open operator station. Cab optional.
|
| Transmission: | 10-speed
|
 Transmission details ... |
| Capacity |
| Fuel: | 150 gal
567.8 L
|
| Hydraulic system: | 80 gal
302.8 L
|
| Steering: | 20 qts
18.9 L
|
| Hydraulics |
| Capacity: | 80 gal
302.8 L
|
| Pump flow: | 43 gpm
162.8 lpm
|
| Steering flow: | 33 gpm
124.9 lpm
|
| Steering cap.: | 20 qts
18.9 L
|
