Wagner WA-9


Wagner WA-9 tractor photo
1961 - 1969
WA Series
Four-wheel Drive (4WD) tractor
Series:WA-4WA-9WA-14
Production
Manufacturer:Wagner
Type:Four-wheel Drive (4WD) tractor
Factory:Portland, Oregon, USA
Wagner WA-9 Power
Engine:160 hp
119.3 kW
Wagner WA-9 Engine
Cummins 7.6L 6-cyl diesel
Engine details ...
Mechanical
Chassis:4x4 articulated 4WD
Final drives:planetary
Steering:hydraulic power
Brakes:hydraulic
Cab:Open operator station. Cab optional.
Transmission:10-speed
Transmission details ...
Photos
No photos of the Wagner WA-9 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:95 gal
359.6 L
Hydraulic system:51 gal
193.0 L
Hydraulics
Capacity:51 gal
193.0 L
Pump flow:67 gpm
253.6 lpm
Dimensions & Tires
Wheelbase:122 inches
309 cm
Weight:18100 lbs
8210 kg
Front tire:15-26
Rear tire:15-26
Full dimensions and tires ...
