Tractors > Wagner > WA-4

Wagner WA-4

Wagner WA-4 tractor photo
1961 - 1969   WA Series
Four-wheel Drive (4WD) tractor
Series next:Wagner WA-9






Production:

Manufacturer:Wagner
Factory:Portland, Oregon, USA


Wagner WA-4 Engine:

   General Motors 3.5L 4-cyl diesel
full engine details ...


Capacity:

Fuel:50 gal [189.3 L]


Dimensions & Tires:

Wheelbase:90 inches [228 cm]
Weight:10300 lbs [4672 kg]
Front tire:16.9x26
Rear tire:16.9x26
full dimensions and tires ...


WA-4 Serial Numbers:


- Serial numbers unknown -



Wagner WA-4 Power:

Engine:102 hp [76.1 kW]


Mechanical:

Chassis:4x4 articulated 4WD
Final drives:planetary
Steering:hydraulic power
Brakes:hydraulic
Cab:Open operator station. Cab optional.


Hydraulics:

Pump flow:22 gpm [83.3 lpm]


Battery:
