Wagner TR-6
| | 1955 - 1960 |
| WA Series | | Four-wheel Drive (4WD) tractor |
|
| Production |
| Manufacturer: | Wagner
|
| Type: | Four-wheel Drive (4WD) tractor
|
| Factory: | Portland, Oregon, USA
|
| Wagner TR-6 Power |
| Engine: | 105 hp
78.3 kW
|
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Final drives: | planetary
|
| Steering: | hydraulic power
|
| Brakes: | hydraulic
|
| Cab: | Open operator station. Cab optional.
|
| Transmission: | 8-speed
|
 Transmission details ... |
| Photos |
| No photos of the Wagner TR-6 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel: | 56 gal
212.0 L
|
| Hydraulic system: | 30 gal
113.6 L
|
| Hydraulics |
| Capacity: | 30 gal
113.6 L
|
| Pump flow: | 11 gpm
41.6 lpm
|
| Steering flow: | 11 gpm
41.6 lpm
|
| Page information |
| Last update: | March 16, 2014
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
