CaseIH Farmall 95N


CaseIH Farmall 95N tractor photo
2009 - 2016
Farmall N Series
Orchard/Vineyard tractor
JX1095N
Series:Farmall 75NFarmall 95NFarmall 105N
Farmall 100N
Production
Manufacturer:CaseIH
Type:Orchard/Vineyard tractor
Original price:$50,336 (2014 ROPS )
CaseIH Farmall 95N Power
Engine (gross):95 hp
70.8 kW
PTO (claimed):82 hp
61.1 kW
CaseIH Farmall 95N Engine
FPT 4.5L 4-cyl diesel
Fuel tank:20 gal
75.7 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Final drives:inboard planetary
Differential lock:electro-hydraulic
Steering:hydrostatic power
Brakes:hydraulic wet disc
Cab:Two-post foldable mid ROPS. Cab optional with air-conditioning.
Transmissions:16-speed mechanical shuttle
 16-speed power shuttle
 32-speed power shuttle
Transmission details ...
Photos
No photos of the CaseIH Farmall 95N are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Rear valves:2 or 3
Pump flow:12.7 gpm
48.1 lpm
 16.9 gpm
64.0 lpm (optional)
Total flow:26.4 gpm
99.9 lpm
Steering flow:9.2 gpm
34.8 lpm
Tractor hitch
Rear Type:II
Control:lower link draft sensing
Rear lift (at 24"/610mm):4400 lbs
1995 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:hydraulic dry disc
Rear RPM:540
 540/1000
Dimensions & Tires
Wheelbase:85.6 inches
217 cm
Weight:5820 to 6107 pounds
Front tire:7.50R18
Rear tire:14.9R28
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:120
Battery CCA:800
Battery volts:12
