CaseIH Puma 150


CaseIH Puma 150 tractor photo
2014 - 2023
Model year
Puma Series
Row-Crop tractor
Puma 145
Series:Puma 150Puma 165
Production
Manufacturer:CaseIH
Type:Row-Crop tractor
Factory:Basildon, England
Original price:$136,669 (2014 power shift )
Original price:$144,426 (2014 CVT )
Original price:$155,110 (2015 CVT )
Original price:$146,129 (2015 power shift )
CaseIH Puma 150 Power
Engine:150 hp
111.9 kW
PTO (claimed):125 hp
93.2 kW
Drawbar (tested):101.1 hp
75.4 kW
PTO (tested):141.6 hp
105.6 kW
power test details ...
CaseIH Puma 150 Engine
FPT 6.7L 6-cyl diesel
Fuel tank:71 gal
268.7 L
 86 gal
325.5 L *With 60L auxiliary tank.
Exhaust fluid (DEF):12.7 gal
48.1 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Trailer brakes:hydraulic*Optional
 pneumatic*Optional
Cab:Cab standard with air-conditioning.
Transmissions:18-speed full power shift
 continuously variable transmission (CVT)
Transmission details ...
Photos
No photos of the CaseIH Puma 150 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center pressure flow compensating
Valves:3 to 5
Pump flow:26.5 gpm
100.3 lpm
Total flow:43.5 gpm
164.6 lpm
Steering flow:17 gpm
64.3 lpm
Tractor hitch
Rear Type:II
 III/II*Optional
Rear lift:7900 lbs
3583 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000 (1.375)
 1000/1000E (1.75)
Dimensions & Tires
Wheelbase:107.6 inches
273 cm
 109.8 inches
278 cm *With suspended front axle
Weight:13900 to 14500 pounds
Front tire:380/85R30
Rear tire:460/85R42
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:150
Battery volts:12
