Tractors > Massey Ferguson > 5613

Massey Ferguson 5613

Massey Ferguson 5613 tractor photo
2013 -    5600 Series
Utility tractor
Previous model:Massey Ferguson 5465
Series back:Massey Ferguson 5612






Production:

Manufacturer:Massey Ferguson
Original price (USD)
   $92,950 (2014 )


Massey Ferguson 5613 Engine:

   AGCO Power 4.4L 4-cyl diesel
full engine details ...


Capacity:

Fuel:49 gal [185.5 L]
Exhaust fluid (DEF):6.6 gal [25.0 L]


3-Point Hitch:

Rear Type:II
Control:electronic lower link draft control
Rear lift (at ends):11450 lbs [5193 kg]
Rear lift (at 24"/610mm):8575 lbs [3889 kg]
Front Hitch:II (optional)
Front lift (at ends):5500 lbs [2494 kg]


Power Take-off (PTO):

Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540/540E (1.375)
 540/540E/1000 (1.375)
Engine RPM:540@1920
540E@1964
1000@1560


Dimensions & Tires:

Wheelbase:100.4 inches [255 cm]
Weight:8929 to 10582 pounds
Rear tire:16.9R38
full dimensions and tires ...


Massey Ferguson 5613 attachments:

 front-end loader
all 5613 attachments ...


5613 Serial Numbers:


- Serial numbers unknown -



Massey Ferguson 5613 Power:

Engine:125 hp [93.2 kW]
PTO (claimed):100 hp [74.6 kW]


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Final drives:internal planetary
Differential lock:full locking electro-hydraulic
Steering:hydrostatic power
Brakes:hydraulic wet disc
Trailer brakes:pneumatic (optional)
 hydraulic (optional)
Cab:Cab standard with air-conditioning. Optional mechanical cab suspension. AGCOMMAND (optional)


Hydraulics:

Type:open center
 closed center pressure flow compensated (PFC) optional
Pressure:2900 psi [200.0 bar]
Valves:2 to 4
Pump flow:15 gpm [56.8 lpm]
 26 gpm [98.4 lpm] (Twin Flow)l 29 (closed center)


Electrical:

Ground:negative
Charging system:alternator
Charging amps:120
 175 (optional)


Battery:

Volts:12


Page information:

Last update:November 22, 2013
