Challenger MT545D Tests
|
|
| Tractor Tests | |
| OECD 2775: diesel CVT 4WD | |
| OECD 2788: diesel AutoPower VI 4WD |
| OCED Tractor Test 2775 | |||
| |||
| OCED Tractor Test 2775 | |
| Diesel CVT 4WD March 2013 - April 2013, Link: OCED Tractor Test 2775 file | |
| PTO performance | |
| Max power | 152.1 hp 113.4 kW |
| Fuel use | 8.7 gal/hour 32.9 l/hour |
| Power at rated engine speed | 136.9 hp 102.1 kW |
| Fuel use | 8.3 gal/hour 31.4 l/hour |
| Power at rated PTO speed | 147.0 hp 109.6 kW |
| Fuel use | 8.6 gal/hour 32.6 l/hour |
| Drawbar performance | |
| Max power | 110.0 hp 82.0 kW |
| Fuel use | 8.3 gal/hour 31.4 l/hour |
| Pull at 7.79KPH | |
| Max pull | 15085 lbs 6842 kg |
| Pull at 3.12KPH | |
| OCED Tractor Test 2788 | |||
| |||
| OCED Tractor Test 2788 | |
| Diesel AutoPower VI 4WD November 2012 - July 2013, Link: OCED Tractor Test 2788 file | |
| PTO performance | |
| Max power | 156.2 hp 116.5 kW |
| Fuel use | 8.7 gal/hour 32.9 l/hour |
| Power at rated engine speed | 141.1 hp 105.2 kW |
| Fuel use | 8.2 gal/hour 31.0 l/hour |
| Power at rated PTO speed | 151.9 hp 113.3 kW |
| Fuel use | 8.6 gal/hour 32.6 l/hour |
| Drawbar performance | |
| Max power | 118.7 hp 88.5 kW |
| Fuel use | 7.9 gal/hour 29.9 l/hour |
| Gear 3A used for power test. | |
| Max pull | 13375 lbs 6066 kg |
| Gear 1F used for pull test. | |
